Product Overview
Button Functions
| No. | Button | Function |
| ① | OFF/ON/–/+ | - Turn the knob to switch the unit on or off - Rotate the knob to adjust the volume |
| ② | - Press once to switch between FM and DAB modes - Press & hold to automatically scan and save all available FM or DAB stations | |
| ③ | - Press once to switch among Bluetooth Speaker, MicroSD Card, and USB Drive modes - Press & hold to enter System Settings | |
| ④ | - Press once cycle through Repeat All / Repeat One / Shuffle (MicroSD and USB modes) - Press & hold to enter Shut down settings | |
| ⑤ | Press once to scroll through options | |
| ⑥ | - Press once to mute/unmute (FM and DAB modes) - Press once to play/pause (Bluetooth, MicroSD and USB modes) - Press once to confirm a selection | |
| ⑦ | 0-9 | - Press numbers to tune to an FM/DAB station (e.g., 1-0-6-2 for 106.2 FM) - Press & hold to save the current FM station to a number button (1-9). - Press a number button to play a saved FM station (1-9). - Press a number to play a specific track from the MicroSD card or flash drive. - Press & hold 0 to turn on/off the flashlight |
💡Note:
• Supports MicroSD cards / USB Drive up to 256 GB.
• Compatible file systems: FAT32 / exFAT.
• Supported file formats: MP3, WAV, WMA, APE, FLAC.
⚠️Doesn't support high-resolution audio files with a sampling rate of 88 kHz or above. The bit depth (e.g., 24-bit) doesn’t affect compatibility.
• The unit will only activate the MicroSD, or USD Drive mode after it detects a connected audio source.
• When powered on, they will automatically return to the last-used mode.
