HT4186-Q – Power & Charging Guide

The NB16-Q headphones have a rechargeable battery, while the Audikast-3 transmitter must remain connected to power while in use.

NB16-Q Headphones

Rechargeable battery. Charge using the provided USB-C cable.

Audikast-3 Transmitter

No built-in battery. Keep it connected to USB power while using it.

How to Charge the Headphones

Connect the provided USB-C charging cable to the headphones, then connect the other end to a USB power source. A solid red LED means the headphones are charging.

A full charge takes approximately 2.5 hours.
When the LED turns off, charging is complete and the headphones can be disconnected.
A full charge provides up to 20 hours of use at approximately 60% volume.

Quick charge: Approximately 15 minutes of charging provides up to 3 hours of use.

How to Power the Audikast-3 Transmitter

The Audikast-3 transmitter has no built-in battery.
Connect the provided USB-C cable to the transmitter.
Power it from your TV’s USB port or a compatible USB wall adapter.
Move the transmitter’s power switch to ON and keep it connected to power while using it.

Recommended power: 5V / 500mA–2A

Frequently Asked Questions

Can I use the headphones while they are charging?

Yes. You can use the headphones while they are connected to the charging cable.

Do I have to wait until the battery is low before charging?

No. You can recharge the headphones at any time.

What charger should I use?

Use the provided charging cable with a standard 5V / 1A or 5V / 2A USB charger. Do not use chargers above that amperage.

Why doesn’t the transmitter hold a charge?

This is normal. The transmitter has no built-in battery and must remain connected to USB power while in use.

Something Doesn’t Look Right?

Headphones Are Not Charging

Unplug and reconnect the USB-C cable.
Make sure the cable is fully inserted.
Try another USB power source.
Try another USB-C cable if one is available.

Transmitter Will Not Turn On

Make sure the USB-C power cable is securely connected.
Try another USB power source.
Move the transmitter’s power switch to ON.

Still Having Trouble?

If the headphones will not charge or the transmitter will not power on, contact Avantree Support.

Contact Avantree Support
