Soundbyte T - Buttons, Indicators & Function Table

Product Overview

Button Functions

No.	Button	Function
①	OFF/ON/–/+	- Turn the knob to switch the unit on or off. - Rotate the knob to adjust the volume.
②	FM / SPK SD Card*	Press once to switch between FM, AUX, Bluetooth, and MicroSD card modes.
③	⚙️/OK	Press once to enter System Settings and confirm a selection.
④	SEEK>>/<<SEEK	Press once to scroll through options.
⑤	⏯	- Press once to mute/unmute (FM and AUX modes). - Press once to play/pause (MicroSD and Bluetooth modes).
⑥		- Press once to enter Bluetooth pairing mode for external earphones. - Press once to reconnect to the last paired device. - Press and hold for 3 seconds to disconnect from Bluetooth.
⑦	SCAN	Press once to automatically scan and save all available FM stations.
⑧	PAGE	Press once to cycle through pages 1, 2, 3, and 4 (FM mode only).
⑨	1-5	- Press and hold to save the current FM station to a number button. - Press a number button to play a saved FM station.
⑩	∧/V	Press once to change the FM frequency by ±0.1 MHz.
⑪	EQ	Press once to cycle between Balanced, Voice Clear, and Bass Boost EQ modes.
⑫	⏳	Press once to enter sleep timer settings.
⑬	MIC	Works in Bluetooth mode for making and receiving calls.

💡Note:
• Supports MP3, WMA, WAV, APE, and FLAC files with up to 32GB storage (MicroSD card).
⚠️Doesn't support high-resolution audio files with a sampling rate of 88 kHz or above. The bit depth (e.g., 24-bit) doesn’t affect compatibility.
• The unit will only activate the Micro SD, or AUX mode after it detects a connected audio source.
• When powered on, they will automatically return to the last-used mode.
